CM-8820 Portable Paint Thickness Meter with F Probe 0 2000μm

Name: CM8820 Portable Paint Thickness Meter with F Probe 0 2000μm
Brand: Bestone
Price: 135 USD

Wholesale CM-8820 Portable Paint Thickness Meter with F Probe 0 2000μm from china suppliers

MOQ : 2

Price : US$135

Brand Name : Bestone

Model Number : CM-8820

Certification : CE,ROHS

Place of Origin : CHINA

Payment Terms : T/T,Western Union

Supply Ability : More than 500pcs per month

Delivery Time : 3-5 working days

Packaging Details : plastic carrying case and white paper box

Model NO. : CM-8820

Min. Sample Thickness : 0.3 mm

Accuracy : ± 1~5%N or ± 5 μm

Transport Package : Box and Carrying Bag

Specification : 161 x 69x 32 mm

Trademark : BESTONE

Origin : China

HS Code : 9031809090

Contact Now

Paint Coating Thickness Meter Gauge with F Probe 0~2000μm CM-8820

The CM-8820 coating thickness gauge is a portable measuring instrument designed for fast, accurate, and non-destructive measurement of coating thickness. Suitable for both laboratory environments and harsh field conditions, this versatile instrument accommodates multiple measuring requirements through interchangeable probes. Widely used in manufacturing, metal processing, chemical industries, and quality inspection applications.

CM-8820 Portable Paint Thickness Meter with F Probe 0 2000μm

Measurement Principles & Applications

Principles	Applications	Examples
F Type Magnetic Induction (Iron Base)	Measure thickness of non-magnetic materials on magnetic substrates	Galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminum tile, some alloy tile, paper
NF Type Eddy Current (Aluminum Base)	Measure thickness of non-conductive coatings on non-magnetic metals	Anodizing, varnish, paint, enamel, plastic coatings, powder coatings on aluminum, brass, non-magnetic stainless steel

Key Features

Complies with ISO 2178 standards for laboratory and harsh field conditions
Advanced micro-computer LSI circuit and crystal time base for high accuracy and fast measurement
Wide measuring range with high resolution capabilities
Digital LCD display eliminates reading errors and guesswork
Durable, maintenance-free construction with lightweight ABS plastic housing
Ergonomic design for comfortable handling in either hand

Technical Specifications

Display	4 digits, 10mm LCD
Principle	F Magnetic Induction
Range	0 ~ 2000µm / 0 ~ 80 mil
Resolution	0.1µm (0 ~ 99.9µm) 1µm (over 100µm)
Accuracy	±5%n or 5.0µm
Operating Condition	Temperature: 0 ~ 40°C Humidity: < 80%
Power Supply	4 x 1.5 AA (UM-3) batteries
Size	161 x 69 x 32 mm
Weight	Approximately 260 g (including batteries)

Standard Accessories

Main Unit x 1pc
Probe (F Type) x 1pc
Calibration Base Set (F Type) x 1pc
Calibration Foils (1 set, 4 pieces)
Carrying Case x 1pc
Operation Manual x 1pc
